DHC
Model | ES-48100 | ES-48200 |
Nominal Voltage (V) | 48 | |
Battery Capacity (AH) | 100 | 200 |
Working Voltage Range | 42-56.25V | |
Recommended Charging voltage (V) | 51.75 | |
Recommended Discharge cutoff Voltage(V) | 45 | |
Standard Charging Current (A) | 25 | 50 |
Max Continuous Charging Current(A) | 50 | 100 |
Standard Discharge Current (A) | 25 | 50 |
Max Continuous Discharging Current(A) | 50 | 100 |
Operating Temperature (℃) | -20℃~60℃ (Recommend 10℃~35℃) | |
Allowable humidity range(℃) | 0~95% RH | |
Degree of protection | -20℃~65℃(Recommend 10℃~35℃) | |
Cooling method | Natural air cooling | |
Cycle life | Around 5000 times | |
Max size (W*D*H) mm(Including mounting rack) | 410*630*190 | 465*682*252 |
Gross weight | 50kg | 90kg |
Communication | RS485(CAN optional) | |
Battery Cell | A Grade Prismatic Cell | |
Protection | Built-in Smart BMS | |
Remark | 0.5C Discharge Max: 1C, 80%DOD |
Model | ES-48100 | ES-48200 |
Nominal Voltage (V) | 48 | |
Battery Capacity (AH) | 100 | 200 |
Working Voltage Range | 42-56.25V | |
Recommended Charging voltage (V) | 51.75 | |
Recommended Discharge cutoff Voltage(V) | 45 | |
Standard Charging Current (A) | 25 | 50 |
Max Continuous Charging Current(A) | 50 | 100 |
Standard Discharge Current (A) | 25 | 50 |
Max Continuous Discharging Current(A) | 50 | 100 |
Operating Temperature (℃) | -20℃~60℃ (Recommend 10℃~35℃) | |
Allowable humidity range(℃) | 0~95% RH | |
Degree of protection | -20℃~65℃(Recommend 10℃~35℃) | |
Cooling method | Natural air cooling | |
Cycle life | Around 5000 times | |
Max size (W*D*H) mm(Including mounting rack) | 410*630*190 | 465*682*252 |
Gross weight | 50kg | 90kg |
Communication | RS485(CAN optional) | |
Battery Cell | A Grade Prismatic Cell | |
Protection | Built-in Smart BMS | |
Remark | 0.5C Discharge Max: 1C, 80%DOD |
